CM202A

Multi Sensor Gyro-Stabilised Camera Payload

The best performance for the lowest SWaP

Get the most out of your manned or unmanned aerial vehicle with the flexible, high-performance CM202A multi-sensor camera payload.

Recognized for its unmatched performance, the CM202A is our most popular product, providing partners around the globe with high-quality intelligence, surveillance and reconnaissance.

Years of testing and development gives e you the best performance camera system for the lowest size, weight and power.
CM202

Multi Sensor Gyro-Stabilized Gimbal

Effective Aerial Gas Detection

The advanced CM202 combines cutting-edge software in a compact, rugged and cost-effective system.

The gyro-stabilized, multi-sensor camera ISR payload is engineered to offer you complete customization to give you the best system suited to the needs of your mission.

The low SWaP gimbal is suitable for integration on a UAV, manned aircraft, fixed land system or mobile land vehicle.

This modular design enables UAV Vision to customize a solution for those who require specific functionality from a stabilized ISR system
Customized for Your Mission

Choose between a wide range of sensor configurations to meet your exact payload requirements.

Never Miss a Target

Dual streaming capability lets you record and stream two independent videos, giving both local and remote recordings, which can be transmitted in different formats and compressed to different qualities, using less CPU and a lower bandwidth.

The CM202 offers high definition imagery and footage at day or night, and in cloudy, foggy or smoky conditions.

Detect and track multiple targets at once by tagging up to 5 moving objects within the FOV.

Enhance Your Video Experience

The CM202 contains a high precision motor to reduce vibration, giving you highly stabilized video with improved imagery.

Stabilized video lets you effectively track an object and find out valuable information.

Direct drive allows the gimbal to quickly respond to disturbances, keeping your target in the center of the frame.
Capabilities

Position Accuracy 0.0046° (80 µrad)
Elevation + 130° / - 30°
Azimuth: 360° Continuous
Slew Rate 150°/sec (2.6 Rad/s)
Power 55w
Voltage 9 - 36v
Electronics High Speed 32bit
Communication Link Ethernet / RS232
Physical Dimensions

Weight: 3500g
Depth: 190mm
Height: 295mm
Temperature: 55°C
Video Specifications

Analogue Output Composite
Digital Output H.264 Up To 10 Mbps
Snapshots 1280×720 (Stored on Board)
Configurations

10K Laser Range Finder
1K Laser Range Finder
DISC120R Daylight Sensor
WIR Sensor with Optical Zoom Lens
MWIR Sensor with Optical Zoom Lens
Nano Point
LAW ENFORCEMENT  SECURITY
BORDER PROTECTION EMERGENCY RESPONSE DISASTER MANAGEMENT  SEARCH AND RESCUE  WILDLIFE PROTECTION
You can customise the CM202A to suit your application by choosing between a range of sensor configurations.

The CM202A provides effective performance on multi rotor, fixed wing and rotary wing UAVs; aerostats; and fixed wing and rotary wing aircraft
3500 grms
MWIR
Low SWaP-C
IP66
3500 grms
MWIR
Low SWaP-C
IP66
DAY AND NIGHT INTELLIGENCE

Detect, recognise and identify a moving or static object at day or night with electro-optical (EO) and thermal (SWIR, MWIR or LWIR) lenses. Defog lets you gather more information in foggy conditions, keeping your platform in the air for longer.

OPTIMISED INTELLIGENCE, SURVEILLANCE AND RECONNAISSANCE

Identify an object accurately and make informed decisions with 30x daylight and 13x MWIR continuous optical zoom. Video analytics lets you digitally zoom into an image. You can detect and track multiple targets at once by tagging up to 5 moving objects within the FOV.

IMPROVED VIDEO EXPERIENCE

The CM202A contains a high precision motor to reduce platform vibration, giving you smooth and clear imagery at optimum zoom. Stable imagery improves your object tracking and identification capabilities. Direct drive keeps your target in the centre of the frame by responding quickly to platform disturbances.

RAPID RESPONSE

Imagery is streamed to your team in real-time for instant data analysis.

CUSTOMISED TO SUIT YOUR APPLICATION

Choose between a wide range of sensor configurations to meet your exact payload requirements.

MULTIPLE ENCODING

Dual streaming lets you record and stream two independent videos, giving both local and remote recordings, which can be transmitted in different formats and compressed to different qualities using less CPU and a lower bandwidth. This is achieved in a single independent unit.

SIMPLE INTEGRATION

Ideal for all manned and unmanned aerial systems, the CM202A is a flexible camera payload that can be mounted on the top, nose or belly of a vehicle. Simple hook-up plug and play provides quick deployment.

LONG ENDURANCE ISR

To help you get the most out of your flight, the CM202A is a low power system to provide longer flight times.
CM202U

Multi Sensor Gyro-Stabilised Gimbal with Counter UAS Software

The CM202U is an innovative, multi-sensor, gyro-stabilised gimbal for counter UAS operations.

The entire system is man-portable and robust, and includes object tracking capability, low power consumption, direct drive motors for accurate positioning, Static Target Detection Algorithm, and Moving Target Detector Algorithm.
13x MWIR Optical Zoom
MWIR
5500g
203mm
320mm
Effective Targeting

Automated object detection increases the likelihood of detecting targets that could go unnoticed by an unassisted operator.

Optical Detection Range

On average, the CM202U with Operator Assist has a 40-100% further optical detection range for DJI Phantom sized sUAS than comparable systems (3km UAV detect, 2km PID).

Improved Force Protection

The operator assist function utilises advanced algorithms to detect and track objects of interest in the air and on the ground, reducing operator fatigue and workload to increase the efficiency of your operation.

Benefit from Enhanced Knowledge

The automated detect software system provides operators with live, real-time cues of possible target objects, reducing decision time when identifying UAVs through rapid identification, and helping operators make informed decisions whilst reducing operator error.

Shortens Decision Cycle

The MTD identifies targets in the FOV much quicker than the operator can manually. This shortens the decision cycle for the operator and allows them to prosecute a hostile target sooner. Quicker informed decisions can save lives.

Multiple Target Tracking

Operator assist can track up to 200 targets simultaneously, ensuring that no threat is ignored during a swarm attack.
Capabilities

Position Accuracy 0.0046° (80 μrad)
Elevation +130° / -30°
Azimuth: 360° Continuous
Slew Rate 150° / sec
Power 55W
Voltage 11 - 36V
Electronics
Communication Link Ethernet / RS232
Physical Dimensions

Weight: 5500g
Depth: 203mm
Height: 320mm
Temperature: 55°C
Configurations

DISC120R Daylight Sensor
MWIR Sensor with Optical Zoom Lens
Video Specifications

Analogue Output Composite
Digital Output h.264 MPEG2 TS / (RTP) MPEG4 MPEG2 TS / (RTP)
Snapshots 1280×720 (Stored On Board)
Static Mount
CM202G

Multi Sensor Gyro-Stabilised Gimbal

Effective Aerial Gas Detection

The CM202G Gas Hound is the industry’s first reliable, multi sensor, gyro-stabilised gimbal for gas leak detection and infrastructure integrity patrols.

With years of testing and development, the CM202G offers a field-proven and high-performance system that allows you to meet the industry standard for comprehensive integrity management.
The optical gas imaging sensor detects methane and other gas leaks in refineries, pipelines, storage facilities and other installations.

The system is ideal for both fixed and mobile platforms for continuous monitoring applications.

13x MWIR Optical Zoom
3500g
MWIR
IP66
LOW SWAP-C

Suitable for manned aircraft and UAVs, the CM202G is a lightweight (3500g), compact (190mm x 295mm) and low power system (100W) to help you meet your payload requirements.

ENHANCED INFORMATION GATEHRING

Benefit from traceable and verifiable pipeline integrity data, rapid notification of anomalies, and precise geo-location of leaks, encroachments, environmental concerns, and right of way violations.

MAXIMISE YOUR DETECTION

Crisp MWIR imagery with 13x continuous optical zoom improves your detection capability. Efficient detection of leaks at long and short ranges.

PROMPT DATA GATHERING

High definition daylight footage is streamed simultaneously with thermal leak detection data, which is all overlaid onto a GIS based mapping system. This information is live-streamed to your operator, giving you prompt access to valuable data, and allowing you to make informed decisions.
Capabilities

Position Accuracy 50-meter accuracy to latitude / longitude target
Elevation + 130° / - 30°
Azimuth: 360° continuous
Slew Rate
Power <100 w
Voltage 15-36 v
Electronics ~112 mph
Communication Link Ethernet / RS232
Physical Dimensions

Weight: 3500g
Depth: 190mm
Height: 295mm
Temperature: 55°C
Configurations

DISC120R Daylight Sensor
MWIR Sensor with Optical Zoom Lens
Video Specifications

Analogue Output Composite
Digital Output H.264 Up To 10 Mbps
Snapshots 1280×720 (Stored on Board)
Fixed Wing Aircraft      Fixed Wing UAV      Multi Rotor UAV    Rotary Wing Aircraft      Static Mount
Fixed Wing Aircraft  Fixed Wing UAV  Air Vehicles Lighter  Multi Rotor UAV   Rotary Wing Aircraft Rotary Wing UAV
Fixed Wing Aircraft  Fixed Wing UAV  Air Vehicles Lighter  Multi Rotor UAV   Rotary Wing Aircraft Rotary Wing UAV





UAV Vision design and manufacture high performance, lightweight, gyro-stabilised camera payloads for ISR (Intelligence, Surveillance & Reconnaissance) applications.

Their high quality, stable video systems are successfully utilised on a vast selection of platforms, including unmanned and manned aircraft, lighter than air vehicles, marine vessels, manned and unmanned ground vehicles, and static land platforms.

Their talented and skilled team offer the very best in creating solutions for your unique requirements as well as putting together packages that meet your desired budget and specifications.

Field-proven systems are in use around the world for border surveillance, firefighting, wildlife spotting, disaster management, crowd monitoring and infrastructure inspection applications.

As a market leading solution for high-performance ISR payloads, UAV Vision is well positioned to exceed market expectation in the supply and maintenance of in-demand systems that offer consistency, quality, and reliability.

UAV Vision remains the first choice of many who require a specific custom solution as well as standard product supply.
