ENHANCED YAW STABILITY

When a camera is zoomed in the smallest movements are magnified. Adding an additional layer of stability to the yaw control of the Z3 is a custom designed reaction wheel. This works in tandem with the normal yaw motor to allow for more refined movement.
Z3
GET CLOSER, SEE MORE
MINISTRY OF PUBLIC ORDER CERTIFIED
MINISTRY OF DEFENSE CERTIFIED
ICoC SIGNATORY COMPANY
NATO CERTIFIED (NCAGE CODE G2181)
UNGM REGISTER COMPANY (400640)
We only legal trade with countries/companies that are not under any sanction by the UN and the EU
Copyright 2008 - International Armour, All rights reserved
FLIR VUE™ PRO

Thermal Camera for sUAS
Designed for professional use, FLIR Vue Pro is more than a thermal camera, it is a thermal measurement instrument and data recorder that adds tremendous value to your sUAS operations and services.
Drone Thermal Imaging
Imagery optimized for airborne operations in a wide variety of environment.
Easy Installation
Accepts 5VDC input power and outputs analog video
Easy Set-up & Configuration
Mobile app (iOS and Android) and built-in Bluetooth makes camera set-up a snap
On-Board Recording
Records digital thermal video and stills to an on-board microSD card
PWM Control
Configure and control the camera in the air with up to four PWM inputs
MAVLink Interface
Trigger automated image capture and geo-tag images for mapping & survey missions
FLIR VUE PRO SPECIFICATIONS
Vue Pro
336x256 Resolution with 6.8mm Lens
Vue Pro
336x256 Resolution with 9mm Lens
Vue Pro
336×256 Resolution with 13mm Lens
Vue Pro
640x512 Resolution with 9mm Lens
Vue Pro
640x512 Resolution with 13mm Lens
Vue Pro
640x512 Resolution with 19mm Lens
GENERAL

NameZenmuse Z3
Dimensions105×115×85 mm
Weight262 g

CAMERA

Sensor : CMOS, 1/2.3"
Max Pixels: 12.76 M, Effective Pixels: 12.4M
Lens: 3.5x Optical Zoom, 22-77mm Equivalent
          F2.8 (Wide) - F5.2 (Tele), FOV 92° (Wide) - 35° (Tele)
Photo Resolutions: 4:3 (L: 12M, 4000x3000) | 16:9 (L: 9M, 4000x2250)
Video Resolutions: UHD: 4K (4096x2160) 24/25p
                                         4K (3840x2160) 24/25/30p
                                         2.7K (2704×1520) 24/25/30p
                               FHD: 1920x1080 24/25/30/48/50/60p
Video Quality: Super fine, Fine, Normal
Photo Formats: JPEG, DNG, JPEG+DNG
Video Formats : MOV, MP4
Video Repair Feature: Supported
Working Modes: Capture, Record, Playback
Still Photography Modes: Single shot, Burst shooting:  3/5/7 frames, Auto Exposure
                                         Bracketing (AEB): 3/5 bracketed frames at 0.7EV bias, Time-lapse
Exposure Mode: Auto, Shutter
Exposure Compensation: ±3.0 (1/3 increments)
Metering Mode: Center-weighted metering, Average metering, Spot metering (Area option 12x8)
AE Lock: Supported
Electronic Shutter Speed: 8 - 1/8000s
White Balance: Auto, Sunny, Cloudy, Incandescent, Neon, Custom (2000K-10000K)
ISO Range: 100 - 3200 (video) | 100 - 1600 (photo)
Video Captions: Supported
Anti-flicker: Auto, 50Hz, 60Hz
PAL/NTSC: Supported
Supported SD Cards: MicroSD (SD/SDHC/SDXC

                                   Max. Capacity: 64 GB, Class 10 or UHS-1
Supported File Systems: FAT32 (
32 GB)
                                         exFAT (> 32 GB)
USB Port: USB 2.0 Host/Device

GIMBAL

Angular Vibration Range: ±0.02°
Mount: Detachable
Controllable Range: Tilt: +30° to -90° | Pan: ±320°, Roll: ±15°
Mechanical Range: Tilt: +50° to -140° | Pan: ±330°, Roll: +90° to -50°
Max Controllable Speed:120°/s

ENVIRONMENTAL

Operating Temperature: 14 to 104°F (-10 to 40℃)
Non-Operating Temperature: 14 to 140°F (-10 to 60℃)
INTEGRATED ZOOM

A 7x zoom made up of 3.5x optical and 2x digital lossless zoom creates a 22mm to 77mm equivalent focal length range, making it ideal for industrial applications.
X5
AERIAL IMAGING EVOLVED
THE NEXT EVOLUTION OF AERIAL CAMERAS

Meet the Zenmuse X5, the world’s first mirrorless, compact Micro Four Thirds camera made specifically for aerial photography
and cinematography. Designed to work with the DJI Inspire 1 ready-to-fly platform, the Zenmuse X5 packs a powerful sensor
that’s capable of recording 4K videos at up to 30 fps and capturing still images at 16MP.

Equipped with the standard MFT interchangeable lens mount and allowing full wireless remote control over focus, aperture, and more, the Zenmuse X5 lets you shoot the way you want.

Welcome to the future of aerial imaging
.
GREATER PIXEL CLARITY

Shooting with the Zenmuse X5’s M4/3 sensor results in images that are crisper and more detailed than any previous aerial camera.
When compared with the X3 camera with the original Inspire 1, the difference is clear in images that truly come to life.


16.0 Micro Four Thirds
Zenmuse X5
Zenmuse X5R
SPECIFICATIONS
TAKE CONTROL

With the Zenmuse X5, you have an unprecedented level of control right at your fingertips. In the intuitive auto-focus mode, simply tap on the screen of your mobile device to tell the camera to focus on a specific area.

You can also easily manually change settings such as focus, shutter, and aperture through the user-friendly DJI GO app. With the Zenmuse X5, you are always ready to take control.
ZENMUSE X5R
